PATRIOT SOLARGUARD 1000 Solar Powered Fence Charger, 40 Miles / 140 Acres | Free Shipping and Fence Tester
SolarGuard 1000™ Solar Energizer
SG1000
Free USA Shipping
Free Single Light Fence Tester
1.0 J maximum output energy (1.30 J stored energy)
FEATURES & BENEFITS
Simple and intuitive
· Solar panel and battery integrated in one convenient robust case
· Housing for convenient stowing of fence leads when not in use
· Single flashing LED indicates fence pulse
· Fit and replace the battery with ease
Truly portable
· Easy to carry portable housing
· Allows mounting to existing steel post or wood post
Delivers power where it counts
· More powerful than comparable energizers
· Reliable year round performance in harsh weather
· Includes leads for connecting to existing fence
· Terminals contain metal insert to ensure robust fence connection
Safe and long lasting
· Complies with IEC safety standards
· 3 year warranty
· Rechargeable internal battery included
TECHNICAL INFORMATION
|
DISTANCE RANGE (miles)
|
40 miles
|
|
DISTANCE RANGE (acres)
|
140 acres
|
|
PEAK OUTPUT ENERGY (UP TO)
|
1.00 J
|
|
PEAK STORED ENERGY (UP TO)
|
1.30 J
|
|
OUTPUT VOLTAGE @ 500 Ω
|
5,500 V
|
|
OUTPUT VOLTAGE @ 1,000 Ω
|
7,000 V
|
|
CURRENT CONSUMPTION
|
90 mA @ 13 V
|
|
RECOMMENDED SOLAR PANEL
|
9.6 W
|
For new farmers looking to build a reliable electric fence system from the ground up, the SolarGuard 1000™ Solar Energizer (SG1000) offers the kind of performance and simplicity that sets you up for success. With the capacity to power up to 140 acres (40 miles) and a strong 1.0 joule output, it delivers consistent voltage across your fence line—an essential factor in properly training livestock and maintaining control.
The integrated solar panel and internal rechargeable battery eliminate the need for external power sources, providing steady, low-maintenance operation even in remote areas. Setup is straightforward with included leads, a clear LED pulse indicator to confirm operation, and a portable design that mounts easily to steel T-posts or wooden posts.
Built with durable terminals for solid connections and engineered to perform through changing weather conditions, the SG1000 gives new operators a dependable, professional-grade solution backed by a 3-year warranty—so you can focus on managing your animals, not troubleshooting your fence.
Old Part# 834689
New Part# 8800002-628
